Phanteks Enthoo Pro M - Titanium Green
Phanteks Enthoo Pro M - Titanium Green
The ENTHOO PRO M focuses on delivering great design without compromising price. Water-cooling builds will be a simple task with the help of our innovative radiator bracket and pump mounting locations. Whether you are a system builder or water-cooling enthusiast, the PRO M will give you unlimited possibilities.
Features:
Enthoo Pro M includes 1 x 140mm fan in the rear. Ability to upgrade to additional fans is possible. All fans included are Phanteks’ new redesigned and better performing SP series fans.
Appearance:
-Brushed aluminum look
Clean interior - Hidden PSU and HDD’s
Cooling:
- Optimal airflow - Direct airflow to CPU / GPU
- Comes with 1 Phanteks premium fans
1x PH-F140SP in rear (140mm)
- 3 different installation areas for radiators
(120mm or 140mm form factor).
- Reservoir mounting locations
Functionality:
- 1x Drop-N-Lock SSD brackets included
- Removable HDD cage for installation of long PSU’s (>180mm) / waterpump
- Equiped with removable dustfilters (1x front, 1x bottom, 1x top magnetic)
- Clean cable management using Phanteks' preinstalled Hoop-N-Loop cable ties
- Removable optical drive cage
- Optional 5x HDD bracket for 3.5”/2.5 HDD upgrade
| ||||||||||||
Case Specifications | ||||||||||||
Dimension | 235 mm x 480 mm x 500 mm (W x H x D) 9.25 in x 18.9 in x 19.7 in | |||||||||||
Form Factor | Midtower Chassis | |||||||||||
Material(s) | Plastic Exterior, Steel Chassis | |||||||||||
Motherboard Support | E-ATX *(up to 264mm wide), ATX, Micro ATX, Mini ITX | |||||||||||
Front I/O | 2x USB 3.0, Mic, Headphone, Reset | |||||||||||
Side Window | Yes | |||||||||||
Expansion & Drive Bays | ||||||||||||
Expansion slots | 7 | |||||||||||
Internal 3.5" | 8x (2x included) | |||||||||||
Internal 2.5" (dedicated) | 3x (1x included) | |||||||||||
Cooling | 120mm fan | 140mm fan | ||||||||||
Front | 3x | 2x | ||||||||||
Top | 3x | 2x | ||||||||||
Rear | 1x | 1x (included) | ||||||||||
Liquid Cooling | 120mm radiator | 140mm radiator | ||||||||||
Front | Up to 360 | Up to 280 | ||||||||||
Top | Up to 360 | Up to 280 | ||||||||||
Rear | 120 | 140 | ||||||||||
Clearance | ||||||||||||
Graphic card | 420 mm (16.54 in) No HDD brackets 300 mm (11.8 in) HDD brackets installed | |||||||||||
PSU | 318 mm (12.5 in) | |||||||||||
CPU cooler | 194 mm (7.6 in) | |||||||||||
Cable management | 35 mm (1.38 in) | |||||||||||
Memory clearance (motherboard - fan) | 120mm: 68 mm (2.68 in) 140mm: 48 mm (1.89 in) | |||||||||||
Packaging Information | PH-ES515P | |||||||||||
Package Dimension | 315 mm x 545 mm x 585 mm (WxHxD) | |||||||||||
Net Weight | 7,4 kg (15.4 lbs) | |||||||||||
Gross Weight | 9,0 kg (19.8 lbs) | |||||||||||
Warranty | ||||||||||||
Length | 5 Years Limited |
